Quick Details

  • Type: Other
  • Condition: New
  • Application: Other
  • Packaging Type: Film
  • Packaging Material: Other
  • Automatic Grade: Automatic
  • Driven Type: Hydraulic
  • Voltage: 220-480v
  • Power: 22kw
  • Place of Origin: Jiangsu, China (Mainland)
  • Brand Name: XTPACK
  • Model Number: XTY-600W11075-30
  • Weight: 13tons
  • Dimension(L*W*H): 7950*3950*3500mm
  • Certification: CE
  • After-sales Service Provided: Engineers available to service machinery overseas
  • Usage: compress waste paper,etc

Packaging & Delivery

Packaging Details by containers
Delivery Time 50-60 days;



Product Description

Features:

  • Photoelectric switch activates baler when charge box is full

  • Unique double-cutting design of cutters improves the cutting efficiency and lengthens the lifespan of the cutters

  • Particular anti-slide design of the machine makes nicer bales

  • Unique trunnion-mounted frame and ball-end joint design for the main cylinder avoid the torque on the rod, which lengthens the lifespan of the seals

  • Equipped with rapid automatic tying system, easy for cleaning and maintaining

  • Use differential technique for the hydraulic system, makes shorter cycle time so that improve the working efficiency and save electricity

  • Automatic tension system ensures "brick-like" bales on all loose materials

  • Adjustable bales length and bales quantity accumulating function make the operation of the machine more convenient

  • Automatically detect and show the errors of the machine which improve the machine inspection efficiency

  • International standard electric circuit layout, graphic operation instruction and detailed parts marks makes the operation been more easily understanding and improves the maintenance efficiency

  • The press heads are specially processed by planomiller, ensures the precise running of the ram

  • Use high quality hydraulic system from Taiwan, ensures the stable running of the machine

  • The heavy duty machine body makes sure only flat ground is required by the installation

Specifications

ModelXTY-600W11075-30XTY-800W11075-50
Pressure60tons80tons
Main Motor Power22kw37.5kw
Cooling Systemair cooler / water coolerair cooler / water cooler
Cycle Time (unload)24s16s
Oil Reservoir1100L1100L
Number of Belting4lines4lines
Wire SizeØ2.7-3.0Ø2.7-3.0
Feed Opening Size (L*W)1600*1050mm1600*1050mm
Chamber Size (L*W*H)2100*1100*750mm2100*1100*750mm
Bale Size (L*W*H, L is adjustable)L*1100*750mmL*1100*750mm
Bale Density (OCC)400-500kgs/m3400-500kgs/m3
Throughput (30-60kgs/m3)3-7tons/h4-8tons/h
Machine Weight13tons14tons
Machine Overall Dimension7950*3950*3500mm8100*3900*3500mm
Feeding DeviceConveyorConveyor
Conveyor
Feeding Width1600mm1600mm
Speed12m/min12m/min
Power5.5KW5.5KW
Weight5tons5tons
Overall Dimension9000*2100*4500mm9000*2100*4500mm



Our company

   Our main products include Vertical balers, full automatic horizontal balers, semi-automatic horizontal balers, bagging machines, conveyors, shredding fans etc. We now globally active and play an important role in domestic and overseas market, our products have been exported to Japan, South-East Asia, Europe, America and Africa etc.

   Through our continuous R&D and innovation, we have CE certificate, SGS, ISO9001:2008, TüV and dozens of independent developing patents, our company has been awarded as the National High Tech Enterprise by the government.

Packaging & Shipping

FAQ

Q1.What is baler?

A:A baler can help companies compact their waste into an acceptable form for easy handling,transport,and storage.It can be used to compact various types of reusable resources and waste,such as office paper,corrugated cardboard,plastic,foil and cans,texitle waste,natual and animal fiber,and so on.

Q2.Why use a baler?

A:In order to effiectively handle your recyclable waste or resources,you need a baling machine to compress the waste material into baler.neat and tidy bales not only reduce your storage space,it also reduces your transportation cost because you can certainly load more cardboard bales into a container or truck as compared to the loose ones.

Q3.Where to buy a suitable baler?

A:XTpack is a baling machine manufacture for more than 15 years with CE and XTpack website,can help you narrow down which hydraulic baling presses are idea to bale the waste material you are handling as well as matching it to your expected output capacity.You can choose our standard models and we can also provide customized baling machine.

Q4.Who use a baler?

A:Shopping malls,retail stores,grocery stores,marine vessels,need baling machine to help them compact the waste such as cartons,cardboards,plastic films,so that they can be stored recycling plant.Corrugating and printing company,need baling to compact the waste paper trims.Recycling plants needs baling machine to compact into small bales for easy transportation and save cost.

Q5.How to choose a suitable baler?

a.Type of material you will be baling.For example,if you need a baling press to bale plastic,you should specify the exact type of plastic.-ie PET bottles?HDPE containers,plastic bags?Plastic film?
b.Bale size and output requirement,say how many tons per day or per hour?
