Quick Details

  • Type: Other
  • Condition: New
  • Application: packaging industry
  • Packaging Type: Film
  • Packaging Material: none
  • Automatic Grade: Automatic
  • Driven Type: Hydraulic
  • Voltage: 220-480v
  • Power: 22kw
  • Place of Origin: Shanghai, China (Mainland)
  • Brand Name: XTPACK BALER
  • Model Number: XTY-600W11075-30
  • Weight: 13tons
  • Dimension(L*W*H): 7950*3950*3500mm
  • Certification: CE
  • After-sales Service Provided: Engineers available to service machinery overseas
  • Usage: compress waste paper,etc

Packaging & Delivery

Packaging Details wrapped with films
Delivery Time 50-60 days;
Product Description

Automatic Horizontal Waste Paper Compressor Baling Press Machine

Features:

  • Photoelectric switch activates baler when charge box is full.

  • Unique double-cutting design of cutters  improves the cutting efficiency and lengthens the lifespan of the cutters.

  • Particular anti-slide design of the machine makes nicer bales.

  • Unique trunnion-mounted frame and ball-end joint design for the main cylinder avoid the torque on the rod, which lengthens the lifespan of the seals.

  • Equipped with rapid automatic tying system, easy for cleaning and maintaining.

  • Use differential technique for the hydraulic system, makes shorter cycle time so that improve the working efficiency and save electricity.

  • Automatic tension system ensures "brick-like" bales on all loose materials.

  • Adjustable bales length and bales quantity accumulating function make the operation of the machine more convenient.

  • Automatically detect and show the errors of the machine which improve the machine inspection efficiency.

  • International standard electric circuit layout, graphic operation instruction and detailed parts marks makes the operation been more easily understanding and improves the maintenance efficiency.

  • The press heads are specially processed by planomiller, ensures the precise running of the ram.

  • Use high quality hydraulic system from Taiwan, ensures the stable running of the machine.

  • The heavy duty machine body makes sure only flat ground is required by the installation.

ModelXTY-600W11075-30XTY-800W11075-50
Pressure60tons80tons
Main Motor Power22kw37.5kw
Cooling Systemair cooler / water coolerair cooler / water cooler
Cycle Time (unload)24s16s
Oil Reservoir1000L1100L
Number of Belting4lines4lines
Wire SizeØ2.7-3.0Ø2.7-3.0
Feed Opening Size (L*W)1600*1050mm1600*1050mm
Chamber Size (L*W*H)2100*1100*750mm2100*1100*750mm
Bale Size (L*W*H, L is adjustable)L*1100*750mmL*1100*750mm
Bale Density (OCC)400-500kgs/m3420-500kgs/m3
Throughput (30-60kgs/m3)3-7tons/h4-8tons/h
Machine Weight13tons14tons
Machine Overall Dimension7950*3950*3500mm8100*3900*3500mm
Feeding DeviceConveyorConveyor
Conveyor
Feeding Width1600mm1600mm
Speed12m/min12m/min
Power4/5.5KW4/5.5KW
Weight5tons5tons
Overall Dimension9000*2100*4500mm9000*2100*4500mm
